Example: Coffee cup

Published 2014-02-03 | Author: Mark Wibrow

It may be easy to download and use a free clipart picture of a coffee cup. However, by drawing it using TikZ we can learn something more about TikZ’ capabilities.

Here we can see the use of scopes, shifting, fadings and opacity, and applying postactions.

The code was written by Mark Wibrow and posted on TeX.SE.

Download as: [PDF] [TEX]  •  [Open in Overleaf]

Coffee cup

Do you have a question regarding this example, TikZ or LaTeX in general? Just ask in the LaTeX Forum.
Oder frag auf Deutsch auf TeXwelt.de. En français: TeXnique.fr.

% Coffee cup
% Author: Mark Wibrow
\documentclass{article}
\usepackage{tikz}
\usetikzlibrary{fadings}
\tikzfading[name=fade out,
  inner color=transparent!0, outer color=transparent!100]
\begin{document}
\begin{tikzpicture}
  \foreach \c [count=\i from 0] in {white,red!75!black,blue!25,orange}{

    \tikzset{xshift={mod(\i,2)*3cm}, yshift=-floor(\i/2)*3cm}
    \colorlet{cup}{\c}

    % Saucer
    \begin{scope}[shift={(0,-1-1/16)}]
      \fill [black!87.5, path fading=fade out]
        (0,-2/8) ellipse [x radius=6/4, y radius=3/4];
      \fill [cup, postaction={left color=black, right color=white, opacity=1/3}]
        (0,0) ++(180:5/4) arc (180:360:5/4 and 5/8+1/16);
      \fill [cup, postaction={left color=black!50, right color=white, opacity=1/3}]
        (0,0) ellipse [x radius=5/4, y radius=5/8];
      \fill [cup, postaction={left color=white, right color=black, opacity=1/3}]
        (0,1/16) ellipse [x radius=5/4/2, y radius=5/8/2];
      \fill [cup, postaction={left color=black, right color=white, opacity=1/3}]
        (0,0) ellipse [x radius=5/4/2-1/16, y radius=5/8/2-1/16];
    \end{scope}

    % Handle
    \begin{scope}[shift=(10:7/8), rotate=-30, yslant=1/2, xslant=-1/8]
      \fill [cup, postaction={top color=black, bottom color=white, opacity=1/3}]
        (0,0) arc (130:-100:3/8 and 1/2) -- ++(0,1/4) arc (-100:130:1/8 and 1/4)
        -- cycle;
      \fill [cup, postaction={top color=white, bottom color=black, opacity=1/3}]
        (0,0) arc (130:-100:3/8 and 1/2) -- ++(0,1/32) arc (-100:130:1/4 and 1/3)
        -- cycle;
    \end{scope}

    % Cup
    \fill [cup!25!black, path fading=fade out]
      (0,-1-1/16) ellipse [x radius=3/4, y radius=1/3];
    \fill [cup, postaction={left color=black, right color=white, opacity=1/3/2},
      postaction={bottom color=black, top color=white, opacity=1/3/2}]
      (-1,0) arc (180:360:1 and 5/4);
    \fill [cup, postaction={left color=white, right color=black, opacity=1/3}]
      (0,0) ellipse [x radius=1, y radius=1/2];
    \fill [cup, postaction={left color=black, right color=white, opacity=1/3/2},
      postaction={bottom color=black, top color=white, opacity=1/3/2}]
      (0,0) ellipse [x radius=1-1/16, y radius=1/2-1/16];

    % Coffee
    \begin{scope}
      \clip ellipse [x radius=1-1/16, y radius=1/2-1/16];
      \fill [brown!25!black]
        (0,-1/4) ellipse [x radius=3/4, y radius=3/8];
      \fill [brown!50!black, path fading=fade out]
        (0,-1/4) ellipse [x radius=3/4, y radius=3/8];
    \end{scope}
  }
\end{tikzpicture}
\end{document}
